發動機型號 Engine Model |
YC26H610 |
|
柴油機型式 Type |
直噴、V型、四沖程、水冷 Direct injection,V-type,four-stroke,water-cooled |
|
進氣方式 Aspiration |
增壓中冷 Turbocharged with intercooled |
|
氣缸數（個） Number of Cylinders |
12 |
|
排放 |
國二 |
|
1小時功率 1h Power(KW) |
610 |
|
缸徑/行程 Bore/Stroke(mm) |
135×155 |
|
壓縮比 Compression ratio |
17.5 |
|
總排量 Total Displacement(L) |
25.8 |
|
標定工況燃油消耗率 BSFC@Rated Condition(g/kw.h) |
≤205 |
|
標定工況機油消耗率 BSFC@Oil Rated Condition(g/kw.h) |
≤0.7 |
|
怠速調速率 Idle State Rate(%) |
≤5% |
|
調速方式 Type of Governor |
電子調速 |
|
怠速轉速 Idle Speed(rpm) |
700 |
|
轉速 Rated Speed(rpm) |
1500 |
|
轉向 Direction of rotation |
面向飛輪端逆時針 |
|
起動方式 Anticilckwise facing the flywheel |
24V電壓起動 |
|
噪聲 Noise(db） |
≤117 |
|
煙度 Smoke(FSN) |
≤2.0
|
|
凈重 Net Weight(kg) |
1850
|
|
長*寬*高 Long.wide.high(mm) |
2015*1200*1500
|
|
接口 |
0#18 |
